10*7mm MBBR Filter Media Virgin HDPE Material White Color Bio Medias For Water Treatment

10*7mm MBBR Filter Media Virgin HDPE Material White Color Bio Medias For Water Treatment

    • 10*7mm MBBR Filter Media Virgin HDPE Material White Color Bio Medias For Water Treatment
    • 10*7mm MBBR Filter Media Virgin HDPE Material White Color Bio Medias For Water Treatment
  • 10*7mm MBBR Filter Media Virgin HDPE Material White Color Bio Medias For Water Treatment

    Product Details:

    Place of Origin: China
    Brand Name: smallboss
    Certification: SGS, FDA, ISO9001
    Model Number: PE03

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 cbm
    Price: discuss personally
    Packaging Details: woven bag
    Delivery Time: as your requirement
    Payment Terms: L/C, T/T
    Supply Ability: 230cbm per day
    Contact Now
    Detailed Product Description
    Density: 0.96-0.98g/cm3 Material: HDPE
    Size: 11*7mm Color: White
    Surface Area: 1000m2/m3 Port: Shanghai

    10*7mm MBBR Filter Media Virgin HDPE Material And White Color For Waste Water Treatment




    Small Boss MBBR Filter Media Advantage



    Rapid carrier bio film formation mechanism



    Super decarburization, ammonia nitrogen removal capacity



    Excellent resistance to shock load performance



    Flexible way of engineering application



    Simple operation and maintenance



    Long service life-100% virgin HDPE material.



    Deoxidation and phosphorus removal effect is good



    Small Boss MBBR Biofilm Carries
    We supply a range of biofilter media, This product is sold by the cubic metre. These products are suited to fluidized or moving bed tank systems. These are also called "Biofilm Reactor (MBBR)"systems and are used for treatment of water and wastewater.

    Self cleaning due to turbulence:
    Due to the turbulent movement of the biofilter media in suspension,the filter media is self-cleaning ,requiring no maintenance.This allows the filter to reach optimum effeciveness without the disturbance of periodic maintenance,avoiding unnecessary loss of bacteria within the filter.This allows stable,low levels of ammonia and nitrite within the water.
    The first few of these products are similar to the patented kaldnes media used in fish farming and waste treatment .The design creates an environment for effective nitrification to take place .Twater flow is created by aeration tha circulates the media throughout the vessel .This high suface area of these products traslates into a small physical area needed for the biofiltration unit.
    Due to vigorous mixing of the kaldnes-like media through aeration,the media is self-cleaning,Requiring no maintenance.This allows the filter to reach optimum effectiveness
    Periodic maintenance is not necessary,preventing the unnecessary loss of bacteria and subsequent ammonia and nitrite spikes in the system.

    Media volume needed:
    with good turbulence and aeration, a feed rate of between 0.25 kgs and 0.75 kgs of 40% protein food per day requires 50 litres of media.

    Model Size(mm) Specific Surface Area(m2/m3) Bio-film formation Duration
    (days)
    Nitrification Efficiency Preferential Temperature (ºC) Services life(years) Number of unites per m3
    PE01

    Φ12×9

    >800 5-15 400-1200 <65 ≥10 >660,000
    PE02 Φ11×7 >900 5-15 400-1200 <65 ≥10 >1.038,000
    PE03 Φ10×7 >1000 5-15 400-1200 <65 ≥10 >100,000
    PE04 Φ16×10 >800 5-15 400-1200 <65 ≥10 >3340,000
    PE05 Φ25×12 >500 5-15 400-1200 <65 ≥10 >135,000
    PE06 Φ25×12 >500 5-15 400-1200 <65 ≥10 >97000
    PE07 Φ35×18 >350 5-15 300-800 <65 ≥10 >33000
    PE08 Φ5×10 >3500 5-15 500-1400 <65 ≥10 >2000000
    PE09 Φ15×15 >900 5-15 500-1400 <65 ≥10 >230,000
    PE10 Φ25×8 >1200 5-15 500-1400 <65 ≥10 >140,000

    Density:0.96g/cm3~0.98g/cm3
