Energy Saving Floating Filter Media Simple Operation Maintenance

Energy Saving Floating Filter Media Simple Operation Maintenance

  • Energy Saving Floating Filter Media Simple Operation Maintenance
  • Energy Saving Floating Filter Media Simple Operation Maintenance
  • Energy Saving Floating Filter Media Simple Operation Maintenance
Energy Saving Floating Filter Media Simple Operation Maintenance
Product Details:
Place of Origin: China
Brand Name: Smallboss
Certification: SGS, FDA, ISO9001
Model Number: PE04
Payment & Shipping Terms:
Minimum Order Quantity: 5 cubic meter
Price: discuss personally
Packaging Details: woven bag
Delivery Time: as your requirement qty
Payment Terms: T/T, L/C
Supply Ability: 80,000m³ per year
Contact Now
Detailed Product Description
Density: 0.96-0.98g/cm3 Material: HDPE
Surface Area: Above 800m2/m3 Port: Shanghai Or Ningbo
Color: White Life-span: >15years
High Light:

water filter media

,

filter bio media

Energy Saving Floating Filter Media Simple Operation Maintenance





Tongxiang SmallBoss Special Plastic Products Co., Ltd. is a comprehensive hi-tech enterprise established in 1992 specializing in the research and development, production and sale of environmental friendly products and MBBR biological filter media.Small Bosscompany has cooperated with Singapore Biological Filter Media Research Institute, Shanghai University and Wuhan University to carry out research and development of water treatment filler since 2004. After years of efforts, Small Boss has successfully developed a number of new Biological Filter Medias and obtained 75 national patents for the products including 12 patents for MBBR biological filter media



MBBR filter media is a novel biologically active carrier, it adopts scientific formula, depending

on the nature of water, blending a variety of beneficial microorganisms grow quickly attached trace elements in polymer materials, through a special process modification, constructed, with more than large surface area, hydrophilic, high biological activity, biofilm fast, good effect, good impact resistance.



Main feature:
Special formula and production technology, accelerating biological film formation ;
Larger effective surface area, obtaining more microorganism;

By bio-film decomposing technology, saving sludge return process;

High-efficiency in denitrification and dephosphorization, improving the water quality;

Lower energy consumption, saving space and shorten technology process.



MBBR can be used in any kind of Pond, it’s no need special pond, and it can used the same pond as before if we change the system to MBBR treatment system, what’s the most important thing is MBBR can be full use of pond volume.

Accelerate the reaction rate significantly, compared with the activated sludge process, reaction efficiency 5 ~ 10 times

Simultaneous nitrification and denitrification process,it can be a good denitrification and phosphorus removal

It is no need bracket, just put in the MBBR filter media directly.

MBBR filter media packing free flow and cutting air bubbles in water, increase dissolved oxygen in water, save energy consumption



Small Boss MBBR Filter Media Application

The Sewage plant upgrade project , improve the standard and quantity

New sewage treatment project of MBBR and Biological Aerated Filter process

Biochemical treatment of reclaimed water

River regulation denitrification and phosphorus removal.

Aquaculture in addition to ammonia nitrogen, water purification

Biological filter media is used for biological deodorization tower



Model Size(mm) Specific Surface Area(m2/m3) Bio-film formation Duration
(days)
Nitrification Efficiency Preferential Temperature (ºC) Services life(years) Number of unites per m3
PE01

Φ12×9

>800 5-15 400-1200 <65 10 >660,000
PE02 Φ11×7 >900 5-15 400-1200 <65 10 >1.038,000
PE03 Φ10×7 >1000 5-15 400-1200 <65 10 >100,000
PE04 Φ16×10 >800 5-15 400-1200 <65 10 >3340,000
PE05 Φ25×12 >500 5-15 400-1200 <65 10 >135,000
PE06 Φ25×12 >500 5-15 400-1200 <65 10 >97000
PE07 Φ35×18 >350 5-15 300-800 <65 10 >33000
PE08 Φ5×10 >3500 5-15 500-1400 <65 10 >2000000
PE09 Φ15×15 >900 5-15 500-1400 <65 10 >230,000
PE10 Φ25×8 >1200 5-15 500-1400 <65 10 >140,000






Small Boss MBBR Filter Media Package:

0.1m3/woven bag; 1m3/woven bag;1m3/carton .

20ft container could load 30m3. 40HC container load 70m3
