MBBR Filter Media
>
3D Elastic Filler For Water Treatment

3D Elastic Filler For Water Treatment

Brand Name: Small Boss
Model Number: EF01
MOQ: 5cbm
Price: Depend on qty
Packaging Details: woven bag
Detail Information
Place of Origin:
China
Certification:
SGS,FDA
Name:
Elastic Filler
Color:
White
Use For:
Water Treatment
Diameter:
0.35-0.45MM
Supply Ability:
250M3 PER DAY
Highlight:

Diameter 0.35MM 3D Elastic Filler

,

Diameter 0.45MM Water Treatment Elastic Filler

,

Water Treatment 3D Elastic Filler

Product Description

3D Elastic Filler For Water Treatment



The elastic three-dimensional filler is selected from polyolefins and polyamides with high-quality varieties of corrosion resistance, temperature resistance, and aging resistance. It is mixed with additives such as hydrophilicity, adsorption, and thermal oxygen resistance, and special wire drawing is used to make wool. Process, the thread is interspersed and fixed on the corrosion-resistant, high-strength central rope. Due to the excellent material selection and process formula, moderate rigidity and flexibility, the thread is arranged in a three-dimensional uniformly radiated state, and a suspension type three-dimensional elastic filler monomer is made , The filler can be spread uniformly in all directions in the effective area, so that air, water, and biofilm can be fully mixed and exchanged. The biofilm can not only be uniformly implanted on each thread, but also maintain good activity and The variability of the gap, the ability to obtain an increasingly larger specific surface area during operation, and the ability to carry out good metabolism. This feature and phenomenon is unmatched by other fillers in China.

Product Information:

Product Material:Polyolefin And Polyamide

Construction Process:Knotting And Binding

Product Structure:Combination Of Fiber West And Nylon Yarn

Product Grade:High Quality

Scope Of Application:Biochemical Treatment Of Industrial Organic Wastewater And Urban Sewage

Features:



Compared with hard honeycomb fillers, three-dimensional elastic fillers have greater pore variability and no blockage; compared with soft fillers, the material has a longer life and does not stick to the group; compared with semi-soft fillers, the specific surface area is larger and the film hangs Fast and low cost. Therefore, the filler can be confirmed to be the fourth-generation high-efficiency and energy-saving novel filler following various hard fillers, soft fillers and semi-soft fillers.

Main Technical parameter table (Reference):

Model

(mm)

Length

(m/m3)

Weight

(kg/m3)

Filmed weight

(kg/m3)

Surface area

(m2/m3)

Diameter wire(mm)
Æ150 44 1.4~2.0 64~69 200~310 0.35~0.45
Æ160 39 1.3~1.9 61~66 280 0.35~0.45
Æ180 30 1.2~1.8 57~62 265 0.35~0.45
Æ200 25 1.1~1.7 55~60 250 0.35~0.45
