Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS

Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS

    • Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS
    • Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS
    • Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS
  • Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS

    Product Details:

    Place of Origin: china
    Brand Name: SMALLBOSS
    Certification: FDA, ISO9001, SGS
    Model Number: PE05

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 cubic meter
    Price: based on your qty
    Packaging Details: woven bag
    Delivery Time: based on your requirement
    Payment Terms: L/C, T/T
    Supply Ability: 80,000m³ per year
    Contact Now
    Detailed Product Description
    Material: HDPE DIA: 25mm
    Length: 12mm/10mm Port: Shanghai
    Surface Area: More Than 600m2/m3 Package: Woven Bag

    Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS





    product introduction

    MBBR filter media is a novel biologically active carrier, it adopts scientific formula, depending on the nature of water, blending a variety of beneficial microorganisms grow quickly attached trace elements in polymer materials, through a special process modification, constructed, with more than large surface area, hydrophilic, high biological activity, biofilm fast, good effect, good impact resistance.



    Small Boss MBBR Core technology:

    Special design of surface, stronger bio-film growth capacity;

    Large specific surface area, high voidage, the more periphyton biomass;
    Unique design of structure and shape according to hydromechanics, strong three-dimensional flow dynamics in the water;
    Adding hydrophilic groups and other trace elements, the biofilm formation time only 3-15 days;
    Excellent impact strength, strong gas shear capacity;
    Without any holder, easy to cure, save energy and space.



    Using Scope:

    The sewage plant upgrade project , improve the standard and quantity

    New sewage treatment project of MBBR and biological aerated filter process

    Biochemical treatment of reclaimed water

    River regulation denitrification and phosphorus removal

    Aquaculture in addition to ammonia nitrogen, water purification

    Biological filter media is used for biological deodorization tower



    Small Boss MBBR Filter Media Advantage

    Rapid carrier bio film formation mechanism

    Super decarburization, ammonia nitrogen removal capacity

    Excellent resistance to shock load performance

    Flexible way of engineering application

    Simple operation and maintenance

    Long service life-100% virgin HDPE material.

    Deoxidation and phosphorus removal effect is good



    MBBR form:

    Model Size(mm) Specific Surface Area(m2/m3) Bio-film formation Duration
    (days)
    Nitrification Efficiency Preferential Temperature (ºC) Services life(years) Number of unites per m3
    PE01 Φ12×9 >800 5-15 400-1200 <65 ≥10 >660,000
    PE02 Φ11×7 >900 5-15 400-1200 <65 ≥10 >1.038,000
    PE03 Φ10×7 >1000 5-15 400-1200 <65 ≥10 >100,000
    PE04 Φ16×10 >800 5-15 400-1200 <65 ≥10 >3340,000
    PE05 Φ25×12 >500 5-15 400-1200 <65 ≥10 >135,000
    PE06 Φ25×12 >500 5-15 400-1200 <65 ≥10 >97000
    PE07 Φ35×18 >350 5-15 300-800 <65 ≥10 >33000
    PE08 Φ5×10 >3500 5-15 500-1400 <65 ≥10 >2000000
    PE09 Φ15×15 >900 5-15 500-1400 <65 ≥10 >230,000
    PE10 Φ25×4 >1200 5-15 500-1400 <65 ≥10 >140,000




    Special Formula MBBR Filter Media With Virgin HDPE Material And White Black Color For RAS
