Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance

Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance

  • Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance
  • Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance
  • Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance
Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance
Product Details:
Place of Origin: China
Brand Name: Smallboss
Certification: SGS, FDA, ISO9001
Model Number: PE02
Payment & Shipping Terms:
Minimum Order Quantity: 5 cubic meter
Price: discuss personally
Packaging Details: woven bag
Delivery Time: as your requirement qty
Payment Terms: T/T, L/C
Supply Ability: 80,000m³ per year
Contact Now
Detailed Product Description
Hole Numbers: 4 Porosity: >85
Density: 0.96-0.98 Material: PE
Dosing Raito: 15-68 Size: 11*7mm
High Light:

water treatment filter media

,

bio ball filter

Energy Saving MBBR Aquarium Plastic Filter Media Simple Operation Maintenance



MBBR Technology and Biofilm Carries
MBBR technology is based on the biofilm principle with an active biofilm growing on small specially designed plastic carriers that are kept suspended in the reactor. The technology utilizes the advantages of both activated sludge and other biofilm systems (e.g. biofilters, biorotors etc.) without being restrained by their disadvantages.
The carriers are designed to provide a large protected surface area for the biofilm and optimal conditions for the bacteria culture when the carriers are suspended in water.
Solutions based on MBBR technology is mainly used in the following applications:

+ For new plants, especially those requiring a small footprint and easy operation, for BOD/COD and nitrogen removal

+ As a high loading system in front of existing biological treatment - roughing reactor

+ To increase the amount of nitrifying bacteria in existing activated sludge system using the WOCK OLIVER carrier in a hybrid plant to meet ammonia limits

+ To implement post-treatment to existing plants for process improvements


MBBR Technology
Technical Details
The aerated MBBR uses, as the activated sludge process, the whole volume of an open tank. It is defined as a biofilm system, as the biomass is growing on carriers that move freely within the reactor volume and are kept within the reactors by a sieve at the reactor outlet. The system can be used either for aerobic or anoxic processes. In aerobic processes the biofilm carriers are kept in suspension by the agitation created by air from aeration diffusers, while in anoxic processes a mixer keep the carriers in movement. A schematic of the principle in an implementation of the WOCK OLIVER MBBR technology is shown below




Small Boss MBBR Filter Media Advantage

  • Rapid carrier bio film formation mechanism
  • Super decarburization, ammonia nitrogen removal capacity
  • Excellent resistance to shock load performance
  • Flexible way of engineering application
  • Simple operation and maintenance
  • Long service life-100% virgin HDPE material.
  • Deoxidation and phosphorus removal effect is good



Small Boss MBBR Filter Media Application

  • The Sewage plant upgrade project , improve the standard and quantity
  • New sewage treatment project of MBBR and Biological Aerated Filter process
  • Biochemical treatment of reclaimed water
  • River regulation denitrification and phosphorus removal
  • Aquaculture in addition to ammonia nitrogen, water purification
  • Biological filter media is used for biological deodorization tower


Model Size(mm) Specific Surface Area(m2/m3) Bio-film formation Duration
(days)
Nitrification Efficiency Preferential Temperature (ºC) Services life(years) Number of unites per m3
PE01 Φ12×9 >800 5-15 400-1200 <65 ≥10 >660,000
PE02 Φ11×7 >900 5-15 400-1200 <65 ≥10 >1.038,000
PE03 Φ10×7 >1000 5-15 400-1200 <65 ≥10 >100,000
PE04 Φ16×10 >800 5-15 400-1200 <65 ≥10 >3340,000
PE05 Φ25×12 >500 5-15 400-1200 <65 ≥10 >135,000
PE06 Φ25×12 >500 5-15 400-1200 <65 ≥10 >97000
PE07 Φ35×18 >350 5-15 300-800 <65 ≥10 >33000
PE08 Φ5×10 >3500 5-15 500-1400 <65 ≥10 >2000000
PE09 Φ15×15 >900 5-15 500-1400 <65 ≥10 >230,000
PE10 Φ25×8 >1200 5-15 500-1400 <65 ≥10 >140,000
